PicoCELA’s next-generation mesh Wi-Fi will pave the way for the future of business.
PCWL-0511(for Outside)
IP67 compliant water and dust resistance
Smaller and lighter design than previous models
This next-generation model achieves a compact and lightweight design, along with improved ease of installation. It combines comfortable communication with reduced burden during installation and operation.
| PCWL-0511 (Outside Model) | |||
| Casing size |
L272×H83×D248mm(Excluding the antenna）D590mm（With antenna） |
||
| Weight |
2.2Kg（Excluding the antenna）/ 2.9Kg（With antenna） |
||
| Wireless specifications |
2.4GHz: 802.11b/g/n/ax 5.0GHz: 802.11a/n/ac/a |
PoE |
PoE power supply PoE+ (IEEE802.3at) |
| Data speed |
Max rate: 4.8Gbps |
External Interface |
2.5GbEx 2 |
| MIMO spatial stream |
4×4 |
Power consumption |
Max 30W |
| Peak antenna gain |
2.4GHz: 4.5dBi 5.0GHz: 7.0dBi |
AC adapter compatible |
◯ Option |
| Bluetooth |
4.1 |
Waterproof performance |
IP67 |
| Adaptive Channel Recovery |
◯ |
operating temperature |
-30〜60℃ |
